Straddle Carrier
45 Ton Straddle Carrier
The 45t straddle carrier is primarily designed to efficiently handle containers at sea ports terminals, rail yards and container depots.
Lifting capacity: 45 Ton(tonne)
Models: MG Gantry, Container handler
Travel speed: 50~130m/min(Empty load/Full load)
Hoisting capacity under spreader: 40T
Rotation angle of spreader: ±5 °
Wheel quantity: 3 wheels, 4 wheels straddle carrier
Power supply: Diesel generator / Electric / Lithium battery / Lithium iron phosphate battery(LFP)
Control method: Wireless radio remote control, driver cab control
45 ton straddle carrier supplier type: China manufacturer
45 ton straddle carrier price: $150,000~$200,000
45 Ton Straddle Carrier
45 Ton Straddle Carrier for Sale
45 Ton Container Straddle Carrier Crane is a specialized vehicle used for the transportation and stacking of shipping containers at sea ports, terminals and logistics yards. The 45 ton rubber tire container straddle carrier is primarily designed to efficiently handle containers in a variety of working sites, including seaports, rail yards and container depots.
Businesses across industries benefit from the affordable build of YUANDA electric straddle carriers, which offer a fast return on investment. With reliable, fuel-efficient equipment and easy-to-source spare parts, you can minimize repairs and operating costs for years to come.
A container straddle carrier handler can also help you save work time by improving efficiency and speed. The machine offers 5 minutes offloading from trailer or truck chassis to ground and supports cube, reefer and flat rack containers.
While this container lift equipment serves for many clients worldwide in various industries, including precast, oil&gas, nuclear, aeronautical, aluminium, marine, building materials, logistics, metals, plastics, steel, timber, warehousing, tunneling and rail industry, renewable green energy industry, and represent the ideal solution for handling of raw materials and finished products. YUANDA 45 ton rubber tyred straddle carriers offer the complete package-container handling equipment that’s affordable, fast, low-weight and safe. These carriers are also highly customizable, so you can configure a machine that fits your workflow best.
Rubber Tyred Straddle Carrier Features & Advantages
Rated load capacity/ SWL/ WLL: 45T, 45Ton, 45tn, 45 metric ton.
Heavy load weight: 40 ton
Straddle carriers for freight container handling: 20', 30', 40', 45' container sizes handled
Container spreader, chains, hooks, lifting beams, clamps and other special lifting devices can be equipped on the rubber tyre container straddle carrier to handle the container, steel coil, long concrete beams and bridge girders, metal structure, prefabricated houses, precast concrete segments, rod bars, pipes, wind mill power generators, rotor blades, compressed pressure tanks(LNG LPG CNG), ISO tanks etc.
3 wheel hydrostatic drive straddle carrier
All 4 wheels steering (hydraulic system). Able to climb slopes of up to 10%
Telescopic feature outstanding for moving from indoor to outdoor
Light weight, low wheel load pressure
Electric power supply or diesel engine or EV battery powered straddle carrier
Engine emission standard: Euro Stage III IV V
Compact design, hydraulic system, telescopic column type
SYMC controller, P+F sensor, Amphenol connector.
CAN bus system: It uses data to transmit signals, with long distance and accurate data.
Latest Hydrostatic drive technologies, variable motor speeds and integrated power management reduce operating costs and increase eco-efficiency, step-less speed change, smooth movement.
Reduced maintenance thanks to direct drive units, high-quality components
Wide wheel surface and high elastic coating steel, low ground pressure.
Driver's cab room and wireless remote control for real-time operation.
Hydraulic hand lever: reducing breakdown, easy for operation and maintenance.
Custom configurations for each specific application, automation system available on request
Intermodal Container: 20ft 40ft 45ft
45 Ton 4 Wheels Rubber Tyred Straddle Carrier for Shipping Containers
45 Ton Rubber Tyred Container Straddle Carrier for sale
45 Ton Rubber Tyred Marine Boat Yacht Straddle Carrier
45 Ton Rubber Tired Straddle Carrier for Long Precast Concrete Tube Pipe
45 Ton Double Beam Girder Mobile Straddle Carrier Crane for Steel Coils Handling
45 Ton Straddle Carrier Rubber Tyred Gantry Crane
2 Pieces of 45 Ton GP Type Container Handling Straddle Carrier Gantry Crane
Technical Parameter of 45 Ton Rubber Tyred Straddle Carrier
Model | 45 Ton Straddle carrier, Mobile Gantry, Container handler |
Lifting Capacity(under spreader)(t) | 45 ton, 45 tone, 45T straddle carrier gantry crane |
Span (m) | 5m~40m |
Lifting Height (m) | 5m~18m |
Stack Layers | 2/3/4 |
Container Model | 20′, 30′, 40′, 45′, 20ft, 40ft, 45ft, 20 feet, 40 feet, 45 feet |
Spreader Rotating Angle | ±5° |
Travel Speed (m/min) | Full Load-20/90, Without Load-40/130, 30kph |
Crane Turning Degree | Straight travel, oblique travel, 90° in-situ steering |
Max. Wheel Load (KN) | 310 |
Total Rating (KW) | 230 |
Certification | CE ISO UL SGS |
Control | Driver Cabin Control / Wireless Remote Control |
Power Supply | AC, Electric, Diesel Engine, Electric-diesel Engine, Hybrid power |
Features | Multi-functional, lighter operating weight, Low pressure on the ground, Equipped with specialized spreaders to lift standard-sized 20GP, 40GP, 45HQ containers and gas storage tanks. |
Application Area | Handling modular construction components, vessel assembly warehouse, machinery manufacturing workshop or outdoor storages, quay container transport, modular house building, tubbing handling, etc. |
Straddle Carrier Cost | $110,000~$220,000 |
*Rubber tire container lifting straddle carrier specifications may be subject to change without notice.
Application of 45 Ton Straddle Carrier
The 45 ton shipping container handling straddle carrier is for freight container, ISO tank, battery energy storage container system, sea port terminal, quay side, precast concrete beams, bridges, injection mold, cement, stone, prefab container house, jumbo manufacturing parts, concrete slab, cylindrical parts, pipelines, granite, general manufacturing, etc.
The 45 ton container transporter straddle carrier is widely used at sea port, harbour freight, container yards, railway, steel mill, terminals, intermodal yards, marinas, river shipyard, civil engineering, construction sites, workshops, manufacturing plant, and so on.
We have various types of straddle carrier for sale, custom engineered designs are available for unique applications and special heavy loads. If you want to buy straddle carrier for your workshop, feel free to contact us now for more information.
